Bearing used for the transmission shaft of the casket lowering device. 4 per operating end. Be sure to specify whether for Imperial or Master model.
The Frigid Master casket lowering device is a high-grade lowering device specifically designed for everyday heavy-duty use. The load bearing components of the
Master are twice the size of those found in the Imperial device, making it the safest and most durable device manufactured by Frigid.
Features:
-
Sturdy, cast Aluminum corner housings and ISO-9001 certified Stainless Steel tubing polished to a mirror finish
- 20 ft. long device straps designed to accommodate graves up to 7 ft. in depth
- High quality tempered steel and bronze precision gearing
- Custom, hand-made, speed control components to maintain a smooth, quiet, and controlled lowering speed.
- Stainless Steel brake lever for simple lowering release
- Modular design for compact storage and transportation
- 12-month warranty on parts and labor
Specifications:
- Assembled Size: 58"L x 22"W x 6.5" H, Telescoping to: 92"L x 34"W x 6.5"H (inside dimension)
- Max Load Bearing: 1000 lbs
- Total Unit Weight: 125 lbs (plain package), 170 lbs (placer set package)
The Master Oversized device is 6" (15.24 cm) wider than a regular Master lowering device to accommodate wider caskets. It is a high-grade lowering device specifically designed for everyday heavy-duty use. The load bearing components of the Master Oversize are twice the size of those found in the Imperial device, making it the safest and most durable device manufactured by Frigid.
Features:
-
Sturdy, cast Aluminum corner housings and ISO-9001 certified Stainless Steel tubing polished to a mirror finish
- High quality tempered steel and bronze precision gearing
- Custom, hand-made, speed control components to maintain a smooth, quiet, and controlled lowering speed.
- Stainless Steel brake lever for simple lowering release
- Resists corrosion and maintains appearance
- Modular design for compact storage and transportation
- 12-month warranty on parts and labor
Specifications:
- Assembled Size: 58"L x 28"W x 6.5" H, Telescoping to: 98” L x 40” W x 6.5” H (248.9 x 101.6 x 16.5 cm) inside dimension
- Max Load Bearing: 1000 lbs
- Total Unit Weight: 130 lbs (plain package), 175 lbs (placer set package)
Constructed of the same materials as the regular lowering device stand, the telescoping model is fully adjustable for hillside setup. One end of the telescoping stand adjusts from 10” to 18” (25.4 cm to 45.8 cm) while the other end adjusts from 14” to 26” (35.6 cm to 66 cm). Weight: 95 lbs / (43 kg).
The original lowering device stand provides a sturdy base for the display of your casket lowering device during service. It stands 14” high and is made with stainless steel corner post tubing. All other tubing is polished aluminum. Weight: 50 lbs / (23 kg).
Bearing used to mount the shortlinks inside the corner housing of the casket lowering device. Shortlinks are the 3/4" square piece that sticks outside of the corner housing when the side rails are off of the device. One the inside of the housing, the shortlink mounts the bevel gear on the operating end and has a collar screw on the inside of the tail end of the device. These bearings are important to keep the side rails rotating smoothly and therefore lowering the casket consistently and smoothly. Be sure to specify whether for Imperial or Master model lowering device. 2 bearings per corner housing. Product sold ea.
These bearings fit inside the bearing housing and the housing of the inside of the operating end of the casket lowering device. There are 4 per operating end. Be sure to specify whether for an Imperial or Master model lowering device.
